ESCALERAS CON JAULA
LADSTEP
Realizadas en aleación de aluminio, las escaleras de jaula LADSTEP ofrecen una elevada resistencia mecánica a la corrosión y a los agentes atmosféricos. Gracias a la amplia gama de componentes, el sistema modular responde a cualquier exigencia de diseño.
LADSTEP, las escaleras con jaula a medida de tus necesidades.
Las escaleras con jaula LADSTEP garantizan al usuario la máxima seguridad y al instalador la serenidad de un producto fiable y fácil de montar.
Documentación
Ficha técnica
|
|
|---|---|
CAD Files
|
MODULI SCALA
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADMOD90 | ladder module 0,90 m – 3 steps | 60 | 500 | 900 | 1 |
| LADMOD120 | ladder module 1,20 m - 4 steps | 60 | 500 | 1200 | 1 |
| LADMOD150 | ladder module 1,50 m – 5 steps | 60 | 500 | 1500 | 1 |
| LADMOD180 | ladder module 1,80 m – 6 steps | 60 | 500 | 1800 | 1 |
| LADMOD210 | ladder module 2,10 m – 7 steps | 60 | 500 | 2100 | 1 |
| LADMOD240 | ladder module 2,40 m – 8 steps | 60 | 500 | 2400 | 1 |
ASTE PER GABBIA
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADBAR90 | kit of 5 cage bars 0,90 m | 15 | 25 | 900 | 5 |
| LADBAR120 | kit of 5 cage bars 1,20 m | 15 | 25 | 1200 | 5 |
| LADBAR150 | kit of 5 cage bars 1,50 m | 15 | 25 | 1500 | 5 |
| LADBAR180 | kit of 5 cage bars 1,80 m | 15 | 25 | 1800 | 5 |
| LADBAR210 | kit of 5 cage bars 2,10 m | 15 | 25 | 2100 | 5 |
| LADBAR240 | kit of 5 cage bars 2,40 m | 15 | 25 | 2400 | 5 |
ANELLI
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADRINGIT | cage ring Leg. Decree 81/2008 | 662 | 600 | 40 | 1 |
| LADRINGEU | cage ring EN 14122 | 762 | 700 | 40 | 1 |
PROTEZIONE FINALE
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADEXT130 | Extension 1,30 m | 60 | 30 | 1300 | 1 |
| LADEXTMOB130 | interlocking extension 1,30 m fir easy access to the roof | - | - | - | 2 |
STAFFE
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADBRA150 | bracket for wall spacing 150 mm | 210 | 512 | 60 | 1 |
| LADBRA200 | bracket for wall spacing 200 mm | 260 | 512 | 60 | 1 |
| LADBRA250 | bracket for wall spacing 250 mm | 310 | 512 | 60 | 1 |
| LADBRA300 | bracket for wall spacing 300 mm | 360 | 512 | 60 | 1 |
| LADBRA350 | bracket for wall spacing 350 mm | 410 | 512 | 60 | 1 |
| LADBRA400 | bracket for wall spacing 400 mm + clearance with screws included | 460 | 512 | 60 | 1 |
| LADSTRAP400 | bracket for wall spacing 400 mm + clearance with screws included | 460 | 512 | 60 | 1 |
| LADBRA450 | bracket for wall spacing 450 mm + clearance with screws included | 510 | 512 | 60 | 1 |
| LADSTRAP450 | bracket for wall spacing 450 mm + clearance with screws included | 510 | 512 | 60 | 1 |
| LADBRA500 | bracket for wall spacing 500 mm + clearance with screws included | 560 | 512 | 60 | 1 |
| LADSTRAP500 | bracket for wall spacing 500 mm + clearance with screws included | 560 | 512 | 60 | 1 |
| LADBRA550 | bracket for wall spacing 550 mm + clearance with screws included | 610 | 512 | 60 | 1 |
| LADSTRAP550 | bracket for wall spacing 550 mm + clearance with screws included | 610 | 512 | 60 | 1 |
| LADBRA600 | bracket for wall spacing 600 mm + clearance with screws included | 660 | 512 | 60 | 1 |
| LADSTRAP600 | bracket for wall spacing 600 mm + clearance with screws included | 660 | 512 | 60 | 1 |
| LADBRAMET | fastening kit for bracket on metal sheet – rivets diameter for fastening 4,8 mm – rivets not included | - | 520 | 210 | 1 |
GIUNZIONI
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADJUN | ladder joint | 55 | 25 | 150 | 1 |
TAPPI
| CÓDIGO | descripción | B
[mm]
|
L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|---|
| LADMODCAP | cap for upper upright closure | 60 | 30 | 20 | 1 |
| LADBARCAP | cap for bar closure | 15 | 25 | 15 | 1 |
TARGHETTA
| CÓDIGO | descripción | L
[mm]
|
H
[mm]
|
unid. |
|---|---|---|---|---|
| LADPLATEIT | label Leg. Decree 81/2008 + IT manual | - | 50 | 1 |
| LADPLATEEU | label EN 14122-4+ EN manual | - | 50 | 1 |
FISSAGGI
| CÓDIGO | descripción | unid. |
|---|---|---|
| MMSA26319 | stainless steel screw DIN 7504 A2 K 6,3 mm x 19 mm | 50 |
| MMSA26325 | stainless steel screw DIN 7504 A2 K 6,3 mm x 25 mm | 50 |
MODULO SCALA SDOPPIAMENTO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADDOULAD | double ladder for splitting 2100 mm | 1 |
ASTE PER GABBIA SDOPPIAMENTO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADDOUBAR | kit of 8 splitting rods | 1 |
ANELLI PER SDOPPIAMENTO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADDOURINGIT | splitting rod Legislative Decree 81/2008 | 1 |
| LADDOURINGEU | splitting rod EN 14122 | 1 |
STAFFE SDOPPIAMENTO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADDOUBRA150 | bracket for double ladder wall distance 150 mm | 1 |
| LADDOUBRA300 | bracket for double ladder wall distance 300 mm | 1 |
PEDANE SDOPPIAMENTO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADDOUBORIT | right-hand platform Legislative Decree 81/2008 | 1 |
| LADDOUBOREU | right-hand platform EN 14122 | 1 |
| LADDOUBOLIT | left-hand platform Legislative Decree 81/2008 | 1 |
| LADDOUBOLEU | left-hand platform EN 14122 | 1 |
MANIGLIONI
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADHANDS | kit of 2 lading handles 450 mm | 2 |
PROLUNGA AD INCASTRO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADEXTMOB130 | interlocking extension 1,30 m fir easy access to the roof | 2 |
PEDANE DI SBARCO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADLAND500 | 500 x 500 mm final landing platform, non – slip | 1 |
| LADLAND750 | 500 x 750 mm final landing platform, non – slip | 1 |
KIT PROTEZIONE
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADPROT750 | 750 mm platform protection kit complete with 4 handrails, 2 aluminium toeboards | 1 |
GRADINI DI USCITA
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADEXSTEP150 | safety exit, wall disance 150 mm, (fasteners included) | 1 |
| LADEXSTEP200 | safety exit, wall disance 200 mm, (fasteners included) | 1 |
| LADEXSTEP250 | safety exit, wall disance 250 mm, (fasteners included) | 1 |
PEDANE RIBALTABILI
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADBOARIT | folding or resting platform for ladder sub-division (with lifting and lowering system) Leg. Decree81/2008 | 1 |
| LADBOAREU | folding or resting platform for ladder sub-division (with lifting and lowering system) EN 14122-4 | 1 |
| LADREST | folding resting platform for ladder with lifeline | 1 |
CHIUSURE DI SICUREZZA
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADTRAPIT | safety closure prepared for padlock (not included) Leg.Decree 81/2008 | 1 |
| LADTRAPEU | safety closure prepared for padlock (not included) EN 14122-4 | 1 |
GANCI PER SCALA SEPARATA
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADHOOK | fastening hooks for separate ladder | 2 |
PIEDINI
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADFEREG | kit of 2 adjustable support feets wit holes for fastening to the ground | 2 |
| LADFEHIN | kit of 2 hinged support feets | 2 |
PORTA ANTINTRUSIONE
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADCARPRO | Anti-instrusion metal sheet door prepared for padlocking (padlock not included) | 1 |
| LADCARPRODIST | set of 4 spacers for anti-instrusion door 65 mm | 1 |
CANCELLETTO
| CÓDIGO | descripción | unid. |
|---|---|---|
| LADGATE | exit gate for fixed ladder | 1 |
